The Solution is here
The Sound Down Flooring system is revolutionary in achieving excellent sound attenuation between floors.
Sound Down is designed and tested to achieve industry leading acoustic performance to reduce both Airborne and Impact noise through a range of frequencies.
Working with standard lightweight timber building systems, the implications of working with a concrete mid-floor are avoided, saving both time and money. The key building processes are not delayed and a solid quiet mid-floor is achieved without having to engineer the entire building for concrete.
The market has been demanding a reliable system that will consistently pass acoustic testing.
SOUND DOWN is the game changer they've been calling for.
with university-tested ratings of stc65 and iic63, sound down takes the risk out of building timber structures in multi-unit developments.
Key benefits
Exceeds NZBC Clause G6 Airborne and Impact Sound requirements
STC 65
IIC 63
Incorporates existing 60min fire-rated ceiling-only system so the floor structure is excluded from the fire cell.
Thorough detailed system to reduce risk of poor installation.
Pre-assembled acoustic battens make installation simple.
Compatible with standard building methods.
Faster and more cost-effective alternative to concrete mid-floor systems.
Allows enclosure of building envelope and lining of walls to proceed without delay.
Solid and quiet when living both above and below.
CAD details available upon request.
High Performer Building
Certified Product
SoundDown is proud to be a Certified Product and part of the High Performer Building Suite.
High Performer Building combines the benefits of core innovative building materials to create a new benchmark in quality.
Click here to find out more
See how it works.
The System
SOUNDDOWN is ideal for intertenancy floors where a 60min fire and 55dB rating is required. Clause G6 of the NZ Building code calls for a design rating of 55dB in both STC and IIC and 50dB rating when tested onsite. With University of Auckland tested ratings of STC65 and IIC63, the SOUNDDOWN system gives ample margin for onsite discrepancies and can accommodate any finished flooring surface without risk of failure. Even tiling won't require expensive acoustic adhesives.
Specification Number: SD.65.63.60
STC Rating: 65dB
IIC Rating: 63dB
FRRL Rating: (60)/60/60 (as per GBUC60)
Disclaimer: These drawings have been issued as a guideline. The sequence work covers various building components. Each trade is responsible to ensure their elements are fully installed, including all waterproofing / sealant / flashings as applicable.
